Elastic rubber band cutting machine ES-008

Elastic rubber band cutting machine  ES-008

The Elastic rubber band cutting machine  ES-008  is applied for automatic cutting of  rubber tube and rubber sleeve into small length rubber bands .

The rubber band cutter machine had been equiped with good quality motor which enable it to cut small length rubber bands with precision and fast speed .

The rubber bands automatic cutting machine  cuts tubing OD ranges from  0- 10 mm  , the rubber tube cutting machine is easy to use with  easy operation control board .

The rubber bands cutter machine features with precise same length cut for elastic rubber bands and the finished rubber bands do not stick  to each other compared to other cutting machine in the market. they come off right after the cutting .

Customer will just need to set the total cutting amount , batch amount , unit cutting length ,press the start key the machine will cut automatically for you  ,the rubber sleeve cutting machine speed can also be adjusted to match production requirement.

When cutting material runs out , the machine will stop working which make this machine care free , no need for baby sitting .

【Youtube video  】

【 Product Advantage 】

1, Easy to use , the control board is easy to be managed which the staff  can use the machine right away.

2,  High power precision motor which gurantees  fast speed cutting and same length cutting  , it also make sure each single rubber bands don't stick one another after finished being cut.

3, Full automation , the machine cuts automatically after the setting which save human labour and increase productivity.

4,  High productivity , the machine cutting speed can be adjusted to match the production requirement which result in high productivity.

5, The machine will self stop working and trigger alarm when out of cutting material which requires no baby sitting .

【Technical Data】

Model No.: ES-008

Brand :ＥＳＭＡＩ

Product name : Elastic rubber band cutting machine

Voltage: 220/110V  50/60HZ

Power:２５０Ｗ

Cutting  Heights : 0—10mm

Net Weight : 28KGS

Dimensions:　Ｌ３６０：Ｗ３００：Ｈ３５０ｍｍ

【Processing】

1,Connect the Electrical source and turn on the cutting machine ( The machine flank had a switch )

2,Load the cutting material  near the knife by press the "　＋＂ " _"button for adjustment , let the roller do the job.

3,Set the Cutting Length by press "SET"  then "ＬＥＮ　＂button to set your target  cutting length.

4,Set the Cutting Amount by Press " SET" then "TOL" button to set your target cutting amount pieces.

5, Initiate the  Cutting Sequence by press "Ｒｕｎ‘’button ,then the cutting machine will automatically cut your material into desired cutting length.

Front view

Side view

【Warranty】

All  the spare parts of elastic rubber band cutting machine  except the knife will have one year of free maintainance by changing the spare parts for free

and free shipping of spare parts to overseas clients starting from the issuing date of commercial invoice  after on line diagnosis .

【Packing】

1SET/ CARTON  (The machine will be packed with foam pading material inisde the carton to protect the machine goods against rough hanlding over seas)
